Mesin pemadam kebakaran lahan liar Shacman 4x4

Mobil pemadam kebakaran hutan Shacman F3000 4x4, juga disebut sebagai mobil pemadam kebakaran air Shacman 4x4 atau truk penyelamat kebakaran Shacman.Baru-baru ini, Truk Pemadam Kebakaran Off-road Tangki Air 4 meter kubik Kabin Ganda Drive 4x4 SHACMAN yang dikembangkan oleh POWERSTAR TRUCKS resmi diekspor ke Afrika, menandai langkah penting bagi peralatan pemadam kebakaran kelas atas Tiongkok di pasar internasional. Truk pemadam kebakaran ini telah mendapatkan pengakuan tinggi dari pelanggan Afrika karena kinerja off-roadnya yang luar biasa, kemampuan desain yang kuat, dan kebutuhan pelanggan yang tepat, menambah kilau bagi produk 'Buatan Tiongkok' di panggung internasional.

Sasis Penggerak Semua Roda 4x4 Shaanxi Automobile: Puncak Kinerja Off-road

Sebagai komponen inti dari truk pemadam kebakaran ini, Sasis Penggerak Semua Roda 4x4 Shaanxi Automobile menunjukkan kinerja yang luar biasanya di medan off-road. Medan di Afrika kompleks, dengan gurun yang luas, pegunungan yang terjal, dan hutan yang berlumpur, yang menempatkan tuntutan yang sangat tinggi pada kemampuan dan stabilitas truk pemadam kebakaran. Dengan sistem tenaga yang kuat dan teknologi suspensi canggih, Sasis Penggerak Semua Roda 4x4 Shaanxi Automobile dapat dengan mudah mengatasi berbagai kondisi jalan yang kompleks.

Pertama-tama, sasis penggerak semua roda 4x4 Shaanxi Automobile dilengkapi dengan powertrain yang efisien, dilengkapi dengan mesin torsi tinggi dan gearbox cerdas, memastikan bahwa kendaraan dapat mempertahankan output daya yang kuat saat mendaki dengan kecepatan rendah dan mengemudi dengan kecepatan tinggi. Kedua, sasis mengadopsi sistem penggerak empat roda penuh waktu, yang dapat secara otomatis mendistribusikan torsi sesuai dengan kondisi jalan, memastikan bahwa kendaraan masih memiliki cengkeraman yang sangat baik di jalan yang licin, berlumpur, atau lunak. Selain itu, sasis juga dilengkapi dengan ground clearance yang tinggi dan sistem suspensi yang diperkuat, yang secara efektif meningkatkan kemampuan dan ketahanan benturan kendaraan, memungkinkan kendaraan untuk dengan mudah melewati medan yang kompleks di Afrika.

Tangga belakang yang tahan lama

Sistem penggerak off-road 4x4

Desain penyelamatan kebakaran CAD lengkap

Spesifikasi mobil pemadam kebakaran hutan Shacman 4x4

:

Spesifikasi Sasis

Ground clearance sangat tinggi, dan pedal terendah dari pedal tiga tingkat masih setengah tinggi ban dari tanah, yang cocok untuk RV off-road.

Modifikasi dan kemampuan beradaptasi:

Bumper diatur pada posisi tinggi untuk meningkatkan sudut pendekatan. Desain tiga tingkat kiri, tengah, dan kanan mudah dibongkar dan diperbaiki. Kait trailer internal terintegrasi dan posisi pemasangan winch disediakan.

Suspensi depan, kedua sisi, dan belakang sasis telah menyediakan antarmuka pemasangan untuk perangkat khusus seperti sikat rol, sekop salju, dan blower salju, yang memiliki kemampuan beradaptasi modifikasi yang baik.

Shacman F3000 4X4 off-road chassis is a chassis designed for off-road and special operations, with powerful power and excellent passability. Here are some key information:

Power system:

Equipped with Weichai WP13 engine, the maximum horsepower can reach 550, the displacement is 12.54L, and the peak torque is 2550N·m.

Equipped with imported Allison 4500 6AT gearbox with torque converter, transfer case is ZQC2000, which can reasonably distribute engine power according to working conditions.

Drive and suspension:

Adopt 4X4 full-time four-wheel drive mode, equipped with three differential locks (axle and wheel) to ensure the passability in various complex terrains.

The front and rear axles are Hande 9.5-ton front axle and 13.5-ton double-stage reduction axle, and the rear axle speed ratio is 4.262.

Tire and ground clearance:

Equipped with 14.00R20 off-road tires, the rolling radius is 590mm, which significantly improves the chassis's passability.

The ground clearance is extremely high, and the lowest pedal of the three-stage pedal is still half the height of the tire from the ground, which is suitable for off-road RVs.

Modification and adaptability:

The bumper is arranged at a high position to increase the approach angle. The left, middle and right three-stage design is easy to disassemble and repair. The internal trailer hook is integrated and the winch installation position is reserved.

The front, both sides and rear suspension of the chassis have reserved installation interfaces for special devices such as roller brushes, snow shovels, and snow blowers, which have good modification adaptability.

Driving and safety:

Support C1 driving license driving, equipped with a variety of safety systems, the chassis weight of the whole vehicle is 7.6 tons, and the fuel tank capacity is 400L.

Shaanxi Automobile F3000 4X4 off-road chassis has become the first choice for off-road RVs and special operation vehicles with its powerful power, excellent passability and wide modification adaptability.

The strong design capabilities of fire truck manufacturers: accurately meet customer needs

The successful export of this fire truck is inseparable from the strong design capabilities of fire truck manufacturers. During the research and development process, the manufacturer fully considered the actual needs of the African region, from functional design to detail optimization, and strived to provide customers with the most perfect solution.

First of all, the fire truck adopts a double-row cab design, which can accommodate 6 firefighters, greatly improving the efficiency of teamwork. The interior of the cab is spacious, equipped with comfortable seats and a humanized control system, ensuring that firefighters can still maintain an efficient working state during long-term operations. Secondly, the fire truck is equipped with 4 cubic water tanks, which can store a large amount of water to meet the needs of firefighting operations in Africa. The water tank is made of high-strength materials and has excellent corrosion resistance and impact resistance, ensuring stable operation in harsh environments.

In addition, the fire truck is also equipped with advanced firefighting equipment, including high-pressure water pumps, foam injection systems and multi-functional water cannons, which can quickly respond to various fire scenes. The manufacturer also added explosion-proof devices and thermal insulation layers to the vehicle according to customer needs, further improving the safety and reliability of the vehicle.

Perfectly meet customer needs: the international competitiveness of Made in China

The successful export of this fire truck not only demonstrates the technical strength of Shaanxi Automobile Group and fire truck manufacturers, but also highlights the competitiveness of Made in China in the international market. African customers highly praised the performance and design of the vehicle during the acceptance process, believing that this fire truck perfectly meets their needs and can effectively improve local fire emergency capabilities.

This cooperation has also laid a solid foundation for in-depth cooperation between Chinese companies and the African market. In the future, Shaanxi Automobile Group will continue to uphold the concept of "innovation-driven, quality first", launch more high-performance and high-reliability products, and help Chinese manufacturing go global.
